2.54mm x 15.24mm DIP Plug Headers: Enhanced Board-to-Board Interconnection with Extra-Wide Spacing

[Image: High-quality product photo showing the connector from top and side angles, highlighting the wide row spacing and pin layout.]

Product Summary:

Our 2.54mm x 15.24mm DIP Plug Headers are engineered for applications requiring enhanced PCB interconnection with greater routing space and mechanical stability. Featuring a standard 2.54mm pin pitch and a wide 15.24mm row spacing, they provide a durable and secure mating solution for standard DIP sockets while solving spatial constraints for components and traces.

Key Features

• Extra-Wide DIP Spacing:​Designed with precise 2.54mm (0.1″) between pins and a wide 15.24mm (0.6″) between rows. This provides perfect compatibility with standard DIP sockets and offers superior clearance for PCB routing and taller components.
• Robust Construction:​Manufactured from high-temperature black thermoplastic (PBT, UL94V-0) with gold-plated pins for superior durability, wear resistance, and long-term reliability.
• Secure PCB Mounting:​Features sturdy pins designed for a firm press-fit into printed circuit boards, ensuring stable placement during soldering and operation. The wide footprint offers increased board stability.
• Optimized Mating:​The pin design facilitates easy insertion into and removal from corresponding sockets, simplifying assembly and maintenance.

Primary Advantages

• Proven Reliability:​Excellent mechanical and electrical performance ensures stable signal transmission, even in demanding environments with vibration or temperature fluctuations.
• Enhanced Design Flexibility:​The wide 15.24mm row spacing provides critical space for power traces and component placement between the rows, solving complex layout challenges.
• Seamless Integration:​The standard 2.54mm pin pitch allows for easy design-in with a wide range of DIP sockets, speeding up your development process.
• Cost-Effective Solution:​Offers an optimal balance of high quality and competitive pricing, reducing the total cost of ownership for your projects.

Applications & Use Cases

These DIP plug headers are ideal for applications requiring additional board space and mechanical strength, including:

• Industrial Control Systems:​Programmable Logic Controllers (PLCs), control panels, and high-power interfaces.
• Power Electronics:​Power supplies, inverters, and motor drives where wider traces are needed.
• Telecommunications Equipment:​Routers, switches, and network infrastructure hardware with dense layouts.
• Automotive Electronics:​In-vehicle control units and battery management systems.
• Test & Measurement Instruments:​Data acquisition systems and precision meters.

Specification
